Model | Rated voltage | Water treatment capacity | Operating power | The number of lamp tubes | Size | Flange interface |
UV-H160 | 220V/50Hz | 15T | 160W | 40W×4 | 380×240×960mm | DN50/2" |
UV-H240 | 220V/50Hz | 20T | 240W | 40W×6 | 430×290×960mm | DN65/2.5" |
UV-H320 | 220V/50Hz | 30T | 320W | 40W×8 | 480×340×960mm | DN65/2.5" |
UV-H480 | 220V/50Hz | 50T | 480W | 120W×4 | 660×330×1300mm | DN80/3" |
UV-H720 | 220V/50Hz | 75T | 720W | 120W×6 | 660×330×1300mm | DN100/4" |
UV-H960 | 220V/50Hz | 90T | 960W | 120W×8 | 762×432×1300mm | DN150/6" |
UV-H1200 | 220V/50Hz | 120T | 1200W | 120W×10 | 762×432×1300mm | DN150/6" |
UV-H1920 | 220V/50Hz | 180T | 1920W | 120W×16 | 870×550×1300mm | DN200/8" |
UV-H2700 | 220V/50Hz | 250T | 2700W | 120W×18 | 930×600×1300mm | DN200/8" |
